Qianyiyuan Fiber Optical Distribution Frame


Capacity: Up to 1728 Cores
Dimensions: Variable
Material: Cold-rolled Steel/Stainless Steel
Design Style: Splice and Distribution
Adapter Type: N/A
Applications: Central Office, FTTX
Number of Cable Entries & Exits: N/A
Color: White/Black/Gray/Others


Fully-closed structure with the advantages of good performance of dust-proof, pleasing and neat appearance.
Enough space for fiber distribution and storage space and very easy for installation and operations.
Fully front side operation, convenient for maintenance.
Cable inlet system is installed on the top of the frame which has excellent performances for fixing the cables.
Cables can be inlet either from the top or the bottom of the frame subject to different requirements.
This frame is suitable for both common bundle cables and ribbon type cables.
Reliable cable fixture cover and earth protection device provided.
Integrated splice and distribution unit is adopted. Each unit holds up to 12 FC adapters and up to 24 SC/LC adapters. All units have specially designed slots and can be easily pulled out for operation at any time.
Fiber separation hook of the splice and distribution module (the hook on the left) can be disassembled to fit for both wide and narrow structure frame.
Up to 6 units make up a module.
Work table is provided if one module contains 6 units. Dual SC adapters could double the capacity of Splice and distribution units’ capacities to max 24FO each.
All adapters are installed 40 degrees inclining to the operation surface which is easier for connecting and also protect installers’ eyes from the lights.
No screw needed for installing adapters.
Curvature radius of 40mm.
