| Items |
Specifications |
| Model |
i5 |
| Alignment Method |
Core Alignment |
| Number of Fibers |
Single |
| Applicable Fibers |
SM (G.652 & G.657) / MM (G.651) / DS (G.653) / NZDS (G.655) / CS (G.654) / EDF |
| Coating Diameter |
100pm – 3mm |
| Cladding Diameter |
80 – 150pm |
| Cleave Length |
5 – 16mm |
| Typical Splice Loss |
SM: 0.01 dB / MM: 0.01 dB / DS: 0.03dB / NZDS: 0.03dB / G.657: 0.01 dB |
| Return Loss |
» 60dB |
| Splice Time |
Quick mode: Avg. 4 sec / SM mode: Avg. 5sec |
| Splice Programs |
Max 128 modes |
| Automatic Calibration |
Automatic Arc Calibration by air pressure & temperature |
| Electrode Life span |
6000 Arc Discharges |
| Heating Programs |
Max 32 modes |
| Heating Time |
13 sec (45mm, 60mm slim) |
| Protection Sleeve |
20mm – 60mm |
| Data Output |
USB-C |
| Splice Memory |
20,000 Splice data / 20,000 Splice image |
| Battery |
Battery Capacity: 7000mAh / Operation Cycle: 400 cycles (Splicing + Heating) |
| Power Supply |
AC Input 100 – 240V, DC Input 9 – 19V |
| Monitor |
5″ Color LCD display. Full Touch Screen |
| Magnification |
x360, x520 |
| Size |
160×131 x 145mm |
| Weight |
1.826kg (1.436kg without battery) |
| Pull Test |
1.96-2.25N |
